Grid Laser Classification Information SkateMk2-Ti-G01
All Skate Mk2 models are designated as Class 3R during all procedures of operation.
Class 3R
Radiation in this class is considered low risk but potentially hazardous. The class limit for 3R is 5x the applicable class limit for Class 2 (for visible radiation).
Laser Parameters
| Grid Laser |
Wavelength | 520 ± 10 nm (Green) |
Laser Power for Classification | 4.5mW peak |
Emission Type | CW - 500Hz |
Boresight Deviation | ≤10 mRad |
Beam Divergence (Full Angle) | 17.1° (In Water) - 10x10 Dot Grid |
Focus Distance | Focusable (prefocused to 2000mm) |
