Line Laser Classification Information SkateMk2-Ti-L01
All Skate Mk2 models are designated as Class 3R during all procedures of operation
Class 3R
Radiation in this class is considered low risk but potentially hazardous. The class limit for 3R is 5x the applicable class limit for Class 2 (for visible radiation).
Laser Parameters
| Line Laser |
Wavelength | 520 ± 10 nm (Green) |
Laser Power for Classification | 10mW peak |
Emission Type | CW - 500Hz |
Boresight Deviation | ≤10 mRad |
Beam Divergence (Full Angle) | 53.6° (In Water) - Line |
Focus Distance | Focusable (prefocused to 2000mm) |
