Test setup 1:
No LED connected. Ethernet control. Video over composite
Condition Average Power (W) Peak Power (W) Peak Current (A) @ 24v
Idle 7.80 9.1 0.38
Recording 7.91 13.56 0.565
Burst Mode 7.59 8.40 0.35
Test setup 2:
Aquorea Mk3 LED connected to Aux0. Lamp output set to 100%. LED power limit set to 48W.
Ethernet control. Video over composite.
Condition Average Power (W) Peak Power (W) Peak Current (A) @ 24v
Idle 55.80 57.10 2.38
Recording 55.91 61.56 2.57
Burst Mode 55.59 56.40 2.35
Optional: The Rayfin has an optional built-in Uninterruptible Power Supply (UPS) which has the following benefits:
-
Saves from requiring reboot in case of faulty system power
-
Buffering from system current surges
-
Provides time for the system to save videos, so they don't become corrupted
